Glass Types
Malaysia: Tempered, Laminated & Frosted

Indicative Klang Valley ranges — get a free quote on WhatsApp.

Using the wrong glass type in the wrong location is a safety risk. Malaysian standards and common sense both require safety glass wherever there is a risk of human impact. Here is a plain-language breakdown of every glass type you will encounter in a renovation. For shower screens specifically, see our shower screen types guide →.

Glass types overview

Tempered (toughened) glass

Ordinary glass heated to ~620°C and rapidly cooled, creating a compressed outer surface that is 4× stronger than float glass. When it breaks, it shatters into small rounded pebbles — not dangerous shards. This is the standard safety glass for shower screens, glass doors, side panels, partitions and table tops.

• Cannot be cut or drilled after tempering (all holes and notches must be done before).
• Carry the MS 1498 or AS/NZS 2208 safety mark (etched in corner).
• Common thicknesses for residential use: 8 mm, 10 mm, 12 mm.

Laminated glass

Two (or more) glass panes bonded with a PVB (polyvinyl butyral) interlayer. When it breaks, fragments stick to the interlayer — the glass cracks but holds in place, preventing injury from falling shards. Best for: overhead glazing (skylights, glass roofs), balcony glass railings and anywhere that broken glass could fall on people below.

• Also provides sound insulation and some UV filtering (depending on PVB grade).
• Available as tempered laminated — both strong and holds together — the premium safety option for railings and large overhead panels.
• Thicker and heavier than a single pane of tempered glass.

Frosted & obscure glass

Frosted glass uses acid-etching or sandblasting to create a translucent, privacy surface. Light passes through but the view is obscured. Common uses: bathroom windows, toilet partitions, internal office glass walls. Available in clear frosted (full privacy) and various patterns. Can be tempered — always specify tempered frosted for any shower or door application. Also available as a frosted film applied to clear glass for retrofitting privacy.

Tinted & solar-control glass

Tinted glass has a coloured body (grey, bronze, green, blue) that reduces visible light and solar heat gain. Solar-control (Low-E) glass adds a metallic coating for enhanced heat rejection with minimal visible tinting. Common uses: window glass in facades, sliding glass doors and where solar heat is a concern. Does not provide safety — must be combined with tempered or laminated for impact-prone locations. Popular in Malaysian high-rises for heat reduction.

Where each type is required

Comparison: tempered vs laminated

Thickness guide

• 4–5 mm: regular windows, low-risk areas — float or tempered.
• 6 mm: framed shower screens, small glass panels — tempered.
• 8 mm: glass doors, semi-frameless panels, large partitions — tempered.
• 10–12 mm: frameless shower doors, railings, heavy panels — tempered or laminated.

Cost in Klang Valley

Installation & safety notes

All glass must be supported by adequately strong frames and fixings. Tempered glass cannot be modified after tempering — specify all cutouts, holes and notches before ordering. Use structural silicone (not ordinary household silicone) for bonded glass edges — structural silicone is rated for glass-weight loads and does not shrink. In Malaysia, balcony and staircase glass railings must be designed to withstand a lateral load per UBBL or the engineer’s specification — typically 0.74 kN/m (handrail load) and 1.0 kN/m (barrier load) for residential balconies. Never use ordinary float glass as a balustrade infill, even in a low-floor setting.

When receiving a glass delivery, inspect the etched safety mark on the corner before signing acceptance. If the glass has no MS 1498 or AS/NZS 2208 mark, reject it — an unmarked pane is unverified glass that may be ordinary float. This applies to shower screens, railings, doors and any safety-critical application.

• Handling: large tempered panes (1 m²+) are heavy and brittle at the edges; always use suction cups and edge protection during transport.
• Nickel sulphide (NiS) spontaneous breakage: tempered glass very rarely shatters without impact due to NiS inclusions in the glass. Heat-soaked tempered glass (subjected to 290°C oven testing to trigger latent NiS failures before shipment) is the mitigation for high-risk or overhead applications.
• Silicone curing time: allow 24–48 hours for structural silicone to fully cure before loading the glass.

ClickBina’s glass installations use certified safety glass throughout — get a quote.

Glass jobs a homeowner can handle, and where to stop

Most glass work is not DIY, but two jobs genuinely are:

• Applying frosted privacy film to existing clear glass on a bathroom or ground-floor window, which gives the frosted look without replacing the pane.
• Checking every delivered pane for the etched MS 1498 or AS/NZS 2208 mark in the corner before you sign for it, and refusing any unmarked pane meant for a shower, door or railing.

Stop at cutting, drilling or fitting glass. Tempered glass cannot be cut or drilled once made, panes over 1 m² need suction cups and edge protection just to move, and railings and overhead glazing have to meet UBBL loads or an engineer's specification. A dropped or badly fixed 10 mm tempered panel costs more than the installation you tried to save.

What decides the price of glass for your opening

The supply prices on this page swing widely because a few choices stack on top of each other:

• Glass type. Ordinary float glass is the cheapest at RM8–RM15 per sq ft, while laminated 6.38 mm for skylights and overhead glazing sits at RM28–RM45 per sq ft.
• Thickness. Clear tempered goes from RM18–RM28 per sq ft at 8 mm to RM35 and up at 12 mm, and frameless shower doors and railings need 10–12 mm.
• Frosting or tint. Frosted tempered 8 mm is RM22–RM35 per sq ft, a step above clear tempered of the same thickness.
• Cutouts and fixings. Every hole, notch and hinge cutout on tempered glass must be specified before tempering, and frames, clamps and structural silicone come on top of the glass itself.
• What the location requires. Overhead glazing must be laminated and a low window with a sill below 800 mm needs tempered or laminated, so the spot can rule out the cheapest pane.

WhatsApp us where the glass is going, the opening's width and height, and a photo of the frame or wall it fixes to for a free quote.

How a glass enquiry on WhatsApp works

1. Tell us the location (shower, door, railing, partition, skylight or window) and send a photo of the opening with its width and height; we reply within the hour.
2. From that you get a free quote for the glass that location calls for, not simply the cheapest pane.
3. Frameless screens and railings may need a site visit, because nothing can be cut after tempering; that visit is RM150, and we waive it if you proceed.
4. The price you accept is flat, and nothing is added on installation day.

Sources & official references

This guide refers to the laws, regulators, official bodies and references below. Rules, fees and procedures change — always confirm the current position with the source:

• Uniform Building By-Laws 1984 (UBBL) — KPKT — official text of the Act; later amendments are gazetted separately, so check the current position.

How we estimated prices: where this guide gives renovation or service price ranges, those RM figures are typical Klang Valley market ranges for 2026, compiled from contractor quotations and supplier price lists. They are not official or fixed rates — the final price depends on your site, so confirm it on site before you commit. Statutory fees, fines, tax rates and tribunal limits come from the law or official body concerned, not from market quotes.
