Unit with no gravity drain, a cassette dripping into the ceiling, or an error that stops the cooling? Here is what the condensate pump does, why it fails and how to keep it working.
A condensate pump is a small pump that lifts the water an aircon produces up and out when the drain pipe cannot simply run downhill to the outside. You need one when the indoor unit sits below the point where the drain has to leave, or the route out is long and flat: ceiling cassettes and concealed ducted units usually have one, and some wall units in condos and offices need one too. Gravity drains do not fail; pumps do, and a failed pump means water pouring out of the unit or into the ceiling. The usual causes are slime blocking the pump or its float, a kinked or blocked discharge pipe, and a worn pump. A diagnostic visit is RM120 – RM400 (indicative Klang Valley range, 2026), and a chemical wash that clears the slime starts around RM120 – RM180 for a 1.0–1.5HP wall unit.
Every aircon makes water. As warm, humid room air passes over the cold indoor coil, moisture condenses on it, drips into a drain pan and leaves through a drain pipe. In Malaysia's humidity that is a lot of water, which is why our aircon leaking water guide starts with the drain.
Most wall units drain by gravity: the pipe runs gently downhill through the wall to a floor trap, a balcony or the outside. A pump is needed only when that fall is impossible, for example:
| Type | Where it sits | Typical use |
|---|---|---|
| Built-in drain pump | Inside the indoor unit, from the factory | Ceiling cassettes and many concealed ducted units |
| Mini pump in trunking or casing | Next to or under the indoor unit, often hidden in trunking | Wall units with no gravity route |
| Tank (reservoir) pump | A small box with a tank and float | Units that produce more water, or a long lift |
Whatever the type, it has the same parts: a sensor or float that notices water, a pump that lifts it, and a discharge pipe that carries it to a drain. Some also have a safety switch that stops the aircon if the water level gets too high, which is exactly what you want.
| What you see | Likely cause | What to check |
|---|---|---|
| Water pouring out of the unit after years of no problem | Pump failed or blocked | Whether the install has a gravity route or a pump |
| Aircon stops cooling and shows an error; no leak | The pump's safety switch has cut the unit | Water level in the pump or drain pan |
| Loud gurgling, buzzing or rattling from the ceiling or trunking | Pump running dry, air in the line or wear | Pump mounting and water supply to it |
| Water stain spreading on the ceiling below a cassette | Pump or drain line overflowing in the void | Switch off; have the ceiling unit opened |
| Musty smell and slow drain | Slime in the drain pan, float or pump | A chemical wash and pump clean |
The commonest cause by far is slime. The same mould and bacteria that grow in a neglected drain pan get into the pump and its float, which then sticks. That is why a pump problem often turns up on a unit that has missed a few services.
Pumps fail less when the water reaching them is clean. Regular servicing that clears the drain pan and flushes the line is the best protection, and on a ceiling unit it is worth making sure the pump is included in the service, not just the filters. Two practical points from our cassette and ducted aircon guide: insist on a permanent access panel at every ceiling unit and every drain pump, and keep a simple record of what sits above each ceiling.
If you are renovating and can create a gravity route for the drain, do it. A pipe that falls to a drain has no moving parts to fail. Our guide to boxing up aircon trunking covers how pipe routes are hidden neatly.
The same thinking applies when you choose where a new unit goes. A position close to an external wall or a floor trap usually allows a short pipe with a proper fall, while a unit on an internal wall deep inside the home often needs a pump from day one. It is worth asking the installer, before the bracket goes up, how the water will leave and whether that route needs anything that can fail.
Sometimes a pump is added after the fact: a unit relocated to a new wall, a renovation that blocked the old drain, or a wall unit that has always dripped because its pipe never really fell. Before adding one, check whether a gravity route is possible with a different pipe path; if not, the pump needs a power supply taken safely from the unit or a proper point, a discharge route to a real drain, and access for future cleaning. A pump hidden where nobody can reach it is tomorrow's ceiling stain.
Pump repair or replacement is priced after the unit has been checked, because it depends on the type of pump and how it is installed. These are the published starting points (indicative Klang Valley ranges, 2026):
| Job | Indicative price | Source guide |
|---|---|---|
| Diagnostic visit / call-out | RM120 – RM400 | Aircon repair guide |
| Chemical wash that clears slime from the pan and drain (1.0–1.5HP wall unit) | RM120 – RM180 | Aircon leaking water guide |
WhatsApp us your job details for a quote — we reply within the hour.
💬 WhatsApp for a quoteCeiling cassettes and ducted units cost more to open and clean than wall units, and access through a closed plaster ceiling adds to the job; our cassette and ducted guide explains why.
ClickBina services and repairs home and office aircon across KL and Selangor, including drainage problems on wall, cassette and ducted units. Our aircon diagnostic visit is RM120 – RM400, and we check the drain route and the pump before quoting anything. Tell us the unit type, where it is installed and what the water is doing. We reply within the hour, and the price we agree is a flat price with no hidden charges. If a new drain route or ceiling work is part of the fix, we handle whole-house refurbishment and coordinate the trades; a site visit for that work is RM150, waived if you go ahead. See our aircon servicing page.
How we estimated prices: every RM figure is quoted unchanged from the ClickBina guides named above; they are typical Klang Valley market ranges for 2026, not fixed rates.
