From the first laser measure to the day the countertop goes on — how a custom kitchen cabinet job actually runs in the Klang Valley, what each stage should produce, and where to slow down before you pay.
Custom kitchen cabinets are built to the measurements of your kitchen rather than assembled from fixed module widths. That distinction sounds academic until you meet a Malaysian kitchen: a service-yard door that opens inward, a beam dropping 250mm below the ceiling, a meter box in the middle of a wall, a wet kitchen half a step lower than the dry one. Modular systems fill those spaces with filler panels and leave dead corners; custom cabinets are cut to the actual opening, so a 2,340mm wall becomes 2,340mm of storage. The trade-off is that nothing exists until you order it — there is no showroom box to carry home, and every millimetre depends on a measurement taken correctly and a drawing you approved. That is why the process matters as much as the material. If you are still choosing between board types, the cabinet material guide covers carcass and door construction; this page is about how the job is actually run, from first visit to the day you load in your plates.
Everything downstream is built on this half hour. A measurer should turn up with a laser distance meter and a spirit level, not just a tape, and should record more than the wall lengths: floor-to-ceiling height at both ends of each run, wall squareness, the position of every water point, waste pipe, gas point, power socket and switch, the swing of every door and window, beam drops, tile thickness (because a tiled floor raises the plinth line), and the exact model of any appliance you already own. Where the kitchen is not yet tiled or the wall is still to be hacked, the measure has to be re-taken later — a good contractor will say so rather than quietly build to a wall that is about to move.
Two site facts change the price more than most people expect: whether the wall can take a wall cabinet (hollow blockwork and some partitions need different fixings), and whether the floor is level, since a floor that falls across a run means every base cabinet is packed and scribed on site. Ask the measurer what they found. “No problem, standard,” delivered in ten minutes without touching a level, is a measurement you will pay for later.
The render is where you make the decisions that are expensive to reverse. Expect a plan view with dimensions, elevations for each run, and a 3D visual that shows door style, colour and handle type. Look past the pretty lighting and check the boring things: is the cabinet under the hob a drawer stack or a shelf; where does the bin go; is there a filler beside the fridge so the door can open past 90 degrees; is the tall unit deep enough for the oven you actually bought; is there a service gap behind the sink for the waste trap. Renders flatter. A wall cabinet drawn at 320mm deep and built at 300mm looks the same on screen and holds a different number of plates.
The quotation should arrive with the render, and it should be itemised — run by run, with the carcass board, door finish, hardware brand or tier, countertop, and every cut-out and accessory listed separately. A single line reading “kitchen cabinet as per drawing” with one lump sum is not a quotation you can compare or hold anyone to. This is the single biggest source of disputes in the trade, and it has its own guide: what a cabinet quote hides walks through the per-foot-run trap line by line. Whether the 3D itself is free, credited against the job, or charged varies from company to company — agree that in writing before anyone starts drawing.
Nothing goes to the factory until a deposit is paid, because the boards are cut to your sizes and cannot be resold. Across the Malaysian market the norm is around a 50% deposit on order with the balance staged against installation and completion, and it is normal to be asked for it — what is not normal is being asked for it without paperwork. Whatever figure and stages you agree, confirm them in writing: the deposit amount, what the balance stages are and what triggers each one, the final drawing revision number the deposit locks in, the agreed material and hardware specification, an expected delivery window, and who bears the cost if a site dimension changes after the measure.
Two habits protect you. Pay to a registered company account, not a personal one, and keep the receipt tied to the signed drawing. And treat the deposit as the moment the design freezes — changes after cutting starts are chargeable everywhere, because the board is already scrap. Our renovation contract guide covers a fair works agreement if your cabinets are part of a bigger job.
Once the order is frozen, your kitchen becomes a cutting list. The carcass boards are CNC-cut, drilled for hinge cups and shelf pins, and run through an automatic edge bander that applies the edging tape under heat or with a reactive adhesive; doors are cut, banded and either laminated, wrapped, sprayed or assembled as frames depending on the style you chose. The market norm for this stage is two to four weeks, and the honest reasons it stretches are worth knowing: a sprayed or 2K finish needs curing time and a clean booth, a special-order laminate or imported hardware has its own lead time, and factories run long in the weeks before a major festive season when everyone wants the kitchen finished.
Fabrication is also the quiet stage where quality is decided. Edge banding done with a moisture-cured adhesive holds up to steam and heat far better than the cheap hot-melt used on budget work — the reason so many kitchens start peeling at the sink is explained in the cabinet water damage and swelling guide. You will not see any of this on site, so it belongs in the specification you signed, not in a conversation on installation day.
Installation of a typical condo or terrace kitchen takes two to four days as a market norm, and it runs in a fixed order: carcasses first, levelled and packed off the floor and screwed to each other and to the wall; then the base run levelled as one continuous line so the countertop has a flat bed; then wall cabinets hung; then doors, drawers and hardware; then plinths, end panels, fillers and trims; then adjustment. Plumbing and electrical points are connected around this — a sink and tap after the top is on, the hob and hood once the cut-outs exist, sockets and under-cabinet lighting while the runs are still open. Coordinate that sequence with whoever is doing your sink and tap and your hob and hood, because a hood ordered late holds up the whole kitchen.
You do not need to be there for all of it, but be there at two moments: when the base run is levelled (before the top is templated) and at the final walk-through. Expect dust and drilling noise; in a strata building the management office will usually want a works permit and will restrict hours, which our strata renovation rules guide sets out.
This is the stage most people are not warned about, and it is why your kitchen is unusable for a few days after the cabinets look finished. A stone top is not cut from the drawing — it is templated against the cabinets as actually installed, so a fabricator comes after the base run is level and makes a physical or digital template of the real line, including the wall bow, the sink model and the hob cut-out. The slab is then cut, polished and returned to be fitted, which the market norm puts at a few days later; sinks and hobs go in with or just after the top, and the tap and waste are connected last. Countertops are supplied and installed with your cabinets rather than bought separately, and the per-foot-run ranges live on the kitchen countertop guide.
Bring the actual sink and hob to site before templating, not the model numbers — cut-outs are made to the physical item. And a tiled backsplash goes on after the top, so leave it in the programme.
These are market norms for a Klang Valley kitchen of ordinary size and complexity, not a promise attached to any one job (market estimate 2026, indicative Klang Valley):
| Stage | Typical duration | What you should have at the end of it |
|---|---|---|
| Site visit & laser measure | Under an hour | Dimensioned site notes, photos, appliance list |
| 3D render & revisions | Several days to two weeks | Plan, elevations, 3D and an itemised quotation |
| Signed order & deposit | Same day | Signed drawing revision, written payment stages |
| Factory fabrication | 2–4 weeks (market norm) | Cut, banded and finished carcasses and doors |
| Delivery & installation | 2–4 days (market norm) | Levelled runs, doors hung and adjusted |
| Stone templating | After the base run is level | Template of the real installed line |
| Top fitted, sink & hob in | A few days after templating | Working kitchen, cut-outs sealed |
| Snagging & handover | 1–2 visits | Adjusted doors, touch-ups, final photos |
Send us a photo of the job on WhatsApp — we reply with an instant quote.
💬 Get Your Instant QuoteAdd time, not drama, for the predictable delays: a wall that has to be re-tiled, an appliance that arrives in the wrong size, a sprayed finish in a wet week, or a festive-season factory queue.
The same kitchen can be bought three ways, and the difference is who carries the coordination. Factory-direct means dealing with the cabinet maker itself — fewest hands in the chain, but you coordinate the tiler, the plumber, the electrician and the appliance delivery yourself, and you own the risk when two trades disagree about a dimension. A renovation contractor sits between you and the factory and sequences the other trades around it, which is what you want when the cabinets are part of a wider kitchen renovation. An interior designer adds design authorship, sourcing and site supervision across the whole home, priced accordingly.
None of the three is inherently cheaper or safer. What predicts a good outcome is a registered business you can actually find, an itemised quotation, and one named person accountable for the sequence.
Cabinets are quoted per foot run of cabinetry, with the countertop, appliances and wet works separate. These are the market anchors your deposit is being measured against (market estimate 2026, indicative Klang Valley):
| Job type | Price (2026, Klang Valley) | Notes |
|---|---|---|
| Contractor promo packages (small, simple kitchen) | from RM3,100 (premium tier from RM6,000) | advertised promo packages; scope varies widely |
| Typical cabinet set, 15–20 ft run, melamine/laminate | RM4,500 – RM12,000 per job | cabinets only |
| Premium set, 20–30 ft run incl. tall units | RM12,000 – RM25,000 per job | cabinets only |
Per foot run, the material you picked at the render stage is what moves the number (market estimate 2026, indicative Klang Valley):
| Cabinet type | Price (2026, Klang Valley) | Notes |
|---|---|---|
| Melamine board (particleboard / MDF carcass) | RM180 – RM300 per ft run | budget dry kitchen, wardrobes |
| Laminate / HPL door (MDF or plywood carcass) | RM280 – RM420 per ft run | mid-range, most common |
| Moisture-resistant (MR) plywood carcass, laminate door | RM350 – RM600 per ft run | wet-kitchen best value |
| Acrylic or PU / 2K spray door | RM380 – RM600 per ft run | gloss / matte premium finish |
| Full aluminium (3G / 4G frame, powder-coated) | RM400 – RM700 per ft run | waterproof, termite-proof; wood-grain coat at the top end |
Two line items surprise people at the quotation stage rather than the render stage: upgrading the carcass to moisture-resistant plywood in the wet zone (RM30 – RM60 per ft run) and tall or larder units, which the market quotes as a multiplier of roughly 1.6 – 2.2x a base-cabinet foot rather than at the base rate. Both are legitimate; both should be on the quotation before you pay a deposit. The full breakdown lives on the kitchen cabinet cost hub.
One check per stage is enough to catch nearly every problem while it is still cheap to fix:
| Stage | The one thing to check | Why it matters |
|---|---|---|
| Measure | Did they level the floor and record the pipe and socket positions? | Unlevel runs and blocked sockets are found on install day otherwise |
| 3D render | Drawer stacks, bin position, appliance model numbers, filler beside the fridge | These are free to change now and chargeable later |
| Quotation | Is every hinge, runner, end panel, plinth and cut-out itemised? | A lump sum cannot be compared or enforced |
| Deposit | Signed drawing revision number, written payment stages, company account | Ties the money to a specific design, not a conversation |
| Fabrication | Confirmation of the edge banding and carcass board actually used | The stage you never see is the one that decides longevity |
| Install day 1 | Base run levelled end to end before anything is templated | A stone top on an unlevel run cracks or sits proud |
| Templating | Actual sink and hob on site | Cut-outs are made to the physical item, not the catalogue |
| Handover | Every door and drawer opened, closed and adjusted with you present | Adjustment is free at handover and a call-out afterwards |
The pattern behind most cabinet horror stories is the same: money moved before anything was documented. Treat these as reasons to slow down — a company with nothing to hide will not mind. No registered company name, SSM number or business address you can actually verify. A deposit requested to a personal bank account. No showroom, no workshop, and no willingness to say where the boards are cut. A 3D render whose lighting, plants and wall art look suspiciously like another company’s portfolio, or renders that never change no matter what you ask for. A quotation that is one line and one number. Warranty wording that promises “lifetime” without saying what is covered, for how long, and what voids it. And pressure — a discount that expires today, on a kitchen that will take a month to build.
The counterweight is boring paperwork: an itemised quotation, a signed drawing revision, written payment stages, a company account, and a name and number for the person who will be on site. Every one of those is normal in this trade. If asking for them causes friction, that friction is the information.
